E-Commerce backend (Micro-service) — Express, Typescript and Kubernetes (Part 1)

Hi Guys, This is a new tutorial series on creating a e-commerce backend using Express and Kubernetes. In this tutorial we will just create only one dummy express server and then try to deploy it with kubernetes and test.

E-Commerce backend (Micro-service) — Express, Typescript and Kubernetes (Part 1) — figure 1

You should have Node:18 and Docker installed in your local environment.

First create an empty folder named product-service inside your project folder and inside it run this command.

npm init -y

After you give basic details about the project, it will create a package.json file. Now run the following command.

npm install express typescript ts-node @types/express

Now to configure typescript run the following command

npx tsc --init

This will create a file named tsconfig.json. Let’s configure it later. Next step is to create a folder named src and inside it create a file named app.ts.

import express from 'express';

const app = express();
const port = process.env.PORT || 3000;

app.get('/', (req, res) => {
  res.send('Hello, This is Price Service!');
});

app.listen(port, () => {
  console.log(`Server is running on port ${port}`);
});

This is a very simple Express App. Now let’s run and test this.

npx ts-node src/app.ts

This will this app. And if you go to the http://localhost:3000/ you will see the message ‘Hello, This is Price Service!’. Now the other way we can run this is by first compiling the ts code and then run the compiled file.

tsc && node app.js

But having the compiled build files inside the source folder is messy. Go to the tsconfig.json file and add "outDir": "./dist” inside it. This will put all the compiled files inside a folder named dist.

Now let’s configure package.json file. Inside the scripts add scripts for build and run.

{
  "name": "kubernetes-express-test",
  "version": "1.0.0",
  "main": "index.js",
  "scripts": {
    "start": "tsc && node dist/app.js",
    "build": "tsc"
  },
  "keywords": [],
  "author": "",
  "license": "ISC",
  "description": "",
  "dependencies": {
    "@types/express": "^4.17.17",
    "express": "^4.18.2",
    "ts-node": "^10.9.1",
    "typescript": "^5.2.2"
  }
}

Next step is to create the Dockerfile.

# Use an official Node.js runtime as a parent image
FROM node:20-alpine

# Set the working directory inside the container
WORKDIR /usr/src/app

# Copy package.json and package-lock.json to the working directory
COPY package*.json ./

# Install application dependencies
RUN npm install

# Copy the rest of the application code to the working directory
COPY . .

# Build the TypeScript code
RUN npm run build

# Expose the port that your application will run on
EXPOSE 3000

# Define the command to run your application
CMD ["node", "dist/app.js"]

Now we have a dummy express server with a Dockerfile. Let’s test this out using docker. Run the following command.

docker build -t test-service .

After this is finished Run the following

docker run -p 3000:3000 test-service

Go and check the http://localhost:3000/ you should see the same message you saw before. Now most of our work is done. Remaining is to deploy this to a Kubernetes cluster. For this we need Kubernetes installed in our local environment. The easiest options is to use MiniKube.

Run the **minikube start **command and then check the status wuing minikube status.

Now create kubernetes deployment files in a folder named kubernetes. We need to create 2 yaml files for this. One is to describe the deployment and other one is for service description.

apiVersion: apps/v1
kind: Deployment
metadata:
  name: product-service-deployment
spec:
  replicas: 2
  selector:
    matchLabels:
      app: product-service
  template:
    metadata:
      labels:
        app: product-service
    spec:
      containers:
        - name: product-service-container
          image: <USER_NAME>/node-product-service-test
          ports:
            - containerPort: 3000

Service description file

apiVersion: v1
kind: Service
metadata:
  name: product-service
spec:
  selector:
    app: product-service
  ports:
    - protocol: TCP
      port: 80
      targetPort: 3000
  type: LoadBalancer

Now if you check the deployment file, you can see I have put image: <USER_NAME>/node-product-service-test. What this means is I’m accessing the docker image of my product-service from here. To access a docker image from docker hub first you should push it to docker hub.

For this you have to create a dockerhub account and then log in to it using terminal. Then enter the following commands

docker login

docker build -t <USER_NAME>/node-product-service-test

docker push <USER_NAME>/node-product-service-test

Now run the following commands to add these configurations to kubernetes.

kubectl apply -f kubernetes/product-service-deployment.yaml

kubectl apply -f kubernetes/product-service.yaml

Now deploy the product-service to kubernetes cluster using following command.

minikube service product-service

Now this will open a tab in you browser and show the message you saw previously.

In the next tutorials We will look deeply in to more complex concepts.

Github: https://github.com/deBilla/kubernetes-test-node-express

Happy Coding !!!! :PE-Commerce backend (Micro-service) — Express, Typescript and Kubernetes (Part 1)
